LiDAR & Radar Sensor Harness | IATF 16949 Certified | SINNHONG Vietnam & China
In the 2026 era of Software-Defined Vehicles (SDV) and L4 Autonomous Driving, data reliability is the ultimate safety feature. SINNHONG is a premier IATF 16949 certified manufacturer specializing in high-performance LiDAR & Radar Sensor Harnesses. We provide the high-bandwidth, low-latency interconnects required for 4D imaging radar, solid-state LiDAR, and multi-sensor fusion platforms.
With advanced production facilities in Dongguan, China, and our strategic Vietnam factory in Ho Chi Minh City, SINNHONG offers global OEMs and Tier 1 suppliers a resilient dual-base supply chain. Our sensor cabling solutions are engineered for extreme environments, featuring superior EMI/EMC shielding to ensure data integrity for 10Gbps Automotive Ethernet and V2X modules. Partner with SINNHONG for tariff-advantaged sourcing and industrial-grade connectivity that powers the future of smart mobility.
Technical Specs: Precision Engineering for ADAS Sensors
Our sensor assemblies undergo 100% automated high-frequency testing to guarantee signal redundancy and zero-failure performance.
| Feature | Technical Specification | B2B Compliance & Standards |
| Data Rate | 1Gbps to 10Gbps+ (LiDAR) / 77GHz - 81GHz (Radar) | IEEE 802.3ch / 10GBASE-T1 |
| Impedance Control | 100 Ω Differential / 50 Ω Coaxial | USCAR-2 / USCAR-17 |
| Shielding Efficiency | Triple-Layer EMI/RFI Shielding (95% Coverage) | CISPR 25 Class 5 |
| Connector Systems | HFM (FAKRA Mini), HSD, Ethernet, Waterproof Fakra | Rosenberger/TE/Molex Compatible |
| Ingress Protection | IP69K Waterproof & Dustproof | ISO 20653 |
| Vibration Resistance | Grade 4 (Chassis/Engine Mount) | LV 214 / ISO 16750-3 |
| Manufacturing Base | Ho Chi Minh City, Vietnam & Dongguan, China | IATF 16949:2016 |
High-Reliability Connectivity for Autonomous Perception
4D Imaging Radar Optimization: Specifically engineered for the massive data throughput of 4D high-resolution radar, ensuring zero-packet loss during real-time 3D environment mapping.
Resilient Dual-Base Sourcing: Our SINNHONG Vietnam factory provides a tariff-advantaged and geopolitically stable sourcing route for North American and European markets, mitigating global supply chain risks.
Advanced EMI/RFI Robustness: We utilize high-density braiding and specialized foil shielding to protect delicate sensor data from the electromagnetic interference common in high-voltage EV powertrains.
External Grade Durability (IP69K): Our LiDAR interconnects are designed for external mounting on roof pods or bumpers, capable of withstanding high-pressure steam cleaning and extreme thermal cycling.
Signal Redundancy for Safety: Supporting safety-critical ADAS features, our harnesses are designed with redundant paths to meet ASIL-D functional safety requirements.
Sustainable Halogen-Free Materials: Available in recyclable and low-smoke zero-halogen (LSZH) options to support the 2026 ESG and carbon-neutrality goals of modern OEMs.
Autonomous Trucking & Logistics: Heavy-duty, vibration-resistant wiring for roof-mounted LiDAR pods and chassis-mounted radar in driverless freight fleets.
360° Surround View & AEB: Providing the high-speed link for Autonomous Emergency Braking (AEB) and high-definition surround-view camera systems.
Robo-Taxi & Shuttles: High-flex, long-lifecycle cabling for the continuous, high-intensity operation of urban autonomous shuttle services.
V2X & Telematics: Reliable data transmission for Vehicle-to-Everything (V2X) communication modules and precision GNSS/GPS antenna systems.
In-Cabin AI Monitoring: Miniature sensor assemblies for driver fatigue monitoring and occupant detection systems required by new safety regulations.
The customer provides product customization requirements and relevant information.
Our professional technical personnel analyze and evaluate the product requirements, and confirm product details with the customer.
We provide customers with quotations and production plans.
The customer confirms the quotation and production plan, and signs the contract.
We start production and maintain close communication with the customer during the production process.
We complete production and perform strict quality control testing.
We deliver the customized products to the customer and provide after-sales service.
